Ready Mix Concrete Plant

  • Excellent manufacturing team with experience of over 20 years.
  • All can be customized to meet your needs&boost productivity.
  • Passed CE&ISO9001:2008 quality attestation.
  • Long-term cooperated transport company ensure the timely and safe delivery.
  • One-stop service save your precious time.
Leave Message Chat Online

The ready mix concrete plant has a reasonable and compact structure, small covering area and special feeding type. As a leading producer and supplier in Zhengzhou, our company always respect customers’ requirements, selling high-quality ready mix batching plant. At present, our machine has been exported into many foreign countries, and has been accepted by various foreign customers.

Main components of ready mix concrete plant:

This equipment is composed by mixer, materials weighing system, materials conveying system, storage system, control system and other subsidiary facilities. Every system is designed with advanced technology.

Features of ready mix concrete batching plant:

  • Adopt combined structure and modular unit, convenient to install and remove;
  • Adopting the most advanced technologies in the world to ensure high stability and durability.
  • A weighing hopper is used to weigh cement, water and additives, to ensure that the measurement is accurate.
  • Various control system adopt for easy operation.
  • Mixing and aggregate lifting system adopt JS double-shaft compulsory concrete mixer which offers high quality and efficient mixing.

Applications of ready mix plants:

The ready concrete batching plant can be used to mix dry-hard concrete, plastic concrete, liquid concrete and other lightweight aggregate concrete.

Model  HZS25  HZS35  HZS50  HZS75  HZS60  HZS90  HZS120  HZS180
Global parameter Maximum productivity (m3/h)  25  35  50  75  60  90  120  180
Discharging height (m)  1.5–4.2  1.6–4.2  4.2  4.2  4.2  4.2-4.5  4.5  4.5
Working cycle time (s)  72  72  72  72  60  60  60  60
Total power (kw)  50  75  88  110  105  145  210  288
Mixer Model JS500 JS750 JS1000 JS1500 JS1000 JS1500 JS2000 JS3000
Batcher Model PLD800 PLD1200 PLD1600 PLD2400 PLD1600 PLD2400 PLD3200 PLD4800
Pneumatic system Air compressor  1.0–7  1.0–7  1.5–7  1.8–7  1.5–7  1.8–7  1.8–7  1.8–7
Discharge pressure (MPa)  0.8  0.8  0.8  0.8  0.8  0.8  0.8  0.8
Displacement (m3/min)  1.67  1.67  1.67  1.67  1.67  1.67  1.67  1.67
Motor power  5.5  5.5  7.5  11  7.5  11  11×2  11×2
Measurement system Aggregate weighing accuracy  ±2%  ±2%  ±2%  ±2%  ±2%  ±2%  ±2%  ±2%
Cement weighing accuracy  ±1%  ±1%  ±1%  ±1%  ±1%  ±1%  ±1%  ±1%
Water weighing accuracy  ±1%  ±1%  ±1%  ±1%  ±1%  ±1%  ±1%  ±1%
Additive weighing accuracy  ±1%  ±1%  ±1%  ±1%  ±1%  ±1%  ±1%  ±1%
Total weight  16T  23T  28T  37T  36T  46T  52T  70T
